ER = 2.2 copper printed circuit board 0.508 mm Thinckness 1 Oz

Quick Detail :
1. Type : Pcb
2. Material : Rogers
3. Layer : Multilayer
4. Products Size :4*9cm
5. Permittivity :2.2
6. Surface finish :Immersion Silver
Features:
1. Rogers pcb multilayer pcb with high frequency can improvide the products quality ,with high techolonogy treatment improve the life cycle of the products .
2. Immersion gold surface finish make the pcb 's conductive performance enhancements.
3. Multilayer pcb design ,the precision of the pcb improves much more better .
4. Low dielectric : 2.5 dielectric conductivity much more precision .

Parameter:

Description :

RO4000® Laminates

Industry leading RO4000® hydrocarbon ceramic laminates and prepregs offer superior high frequency performance and low cost circuit fabrication resulting in a low loss material which can be fabricated using standard epoxy/glass (FR-4) processes.

RO4000 material possesses the properties needed by designers of RF microwave circuits and matching networks and controlled impedance transmission lines. RO4000 series laminates offer a range of dielectric constants (2.55 - 6.15), are available with UL 94 V-0 flame retardant versions.

High Thermal Performance

• Tg of 200 (DSC), 230°C (DMA)

• Low CTE for reliability

• Lead-free Compatible & Rhos Complaint

• UV Blocking and AOI Fluorescence

• Copper Foil Cladding: Grade 3 (HTE),1/2,1 and 2 oz. Foil Options: Reverse treat

PrePreg Material

It announced TerraGreen, a halogen-free, ultra-low loss, RF/microwave/high-speed material. TerraGreen is engineered for such high-performance applications as power amplifier boards for 4G LTE base stations.

Key Benefits:

• Optimized cost and RF / microwave performance
• Compatible with FR-4 fabrication including multilayer PCB constructions
• High thermal conductivity for improved thermal management over traditional PTFE materials
• Robust lead-free solder processing compatibility
• Low Z-axis CTE for reliable plated through-hole quality

Typical Applications:

• Cellular Base Station Antennas and Power Amplifiers
• Microwave point to point (P2P) links
• Automotive Radar and Sensors
• RF Identification (RFID) Tags
• LNB’s for Direct Broadcast Satellites

Production Description :

Competitive Advantage:
1) With UL,ROHS,ISO,IPC
2).Lead time:3-10 working days
3)Competitive price best quality
4).Rich 20 years experience in High Tg Multilayer PCB .


What Information customer need to provide for quotation ?
1. PCB Gerber files ,protel,powerpcb,Autocad,etc.
2. BOM list for PCB assembly.
3. Send us your sample PCB or PCBA.
4. OEM is acceptable.

Detailed Image

Payment :

Xinchenger Electronics co.,Ltd established in 2009,we have committed ourselves to manufacturing various of printed circuit boards.

We have accumulated abundant experiences in the line of high frequency microwave business for which widely apply to power divider,combiner,power amplifier,line amplifier,base station,RF antena,4G antena so on and so forth. Our company's sufficient stocks of hi-frequency pcb materials such as Rogers,TACONIC,Arlon,Isola,F4B,TP-2,FR-4 (dielectric rage:2.2-16) mainly used in the area of high technologies like communication device,Electronics,Aerospace,Military industry to meet our worldwide customers with high quality. Furthermore,we also keen on helping customers shorten the period of production development and 24 hours of sample service is available.

Since the day of company foundation we continuously engaged in researching special and high precision printed circuit boards with the strong production capability of 2 to 28 layers of highly precise impedence,multi-layer blind buried,multi-layer mix-compression,high TG, copper substrate,Ceramic substrate PCB. We emphasize the significance of traning program for every single staff in the company even grass-roots employees which becomes the most competitive factors to excel from others,our company have many experienced and professional teams from management to production line,30% are highly educated among the total amount of employees,advanced engineers and senior technicians are up to 80 people.

With advanced foreign technology supports and domestic 3G/4G device manufacturer in microwave pcb field which lead our experienced hi-frequency researching team to one step ahead of the line of printed circuit board business,we are honored to obtain sound reputations over our worldwide customers on the basis of fine qulity,prompt delivery,satisfied after sales service for may years and we assure our customers that we will return the favors with more and more superior products in the near future.
