Multilayer High Frequency Taconic Pcb With TLY Military Grade Very Low DK Base Material Low Cost RF Laminate

Quick Detail :
1. Type : Pcb
2. Material : PTFE
3. Layer : Multilayer
4. Products Size :12*3cm
5. Permittivity : 3.5
6. Surface finish : Immersion Gold

Features:
1. oven glass laminates are constructed with a woven matrix of fiber-glass fabric coated with PTFE that is more mechanically stable and has a more uniform dielectric constant than traditional non-woven products. The laminates are dimensionally stable, and exhibit virtually no moisture absorption during fabrication process.
2. Immersion gold surface finish make the pcb 's conductive performance enhancements.
3. Multilayer pcb design ,the precision of the pcb improves much more better .
4. Low dielectric : 2.5 dielectric conductivity much more precision .

Parameter:

Description :

with aTg > 170º C

Taconic Advanced Dielectric Division manufactures PTFE/woven glass base materials for microwave, RF and high speed digital applications. Applications include LNAs, LNBs, PCS/PCN antennas, GSM and UMTS antennas, power amplifiers, filters, passive components, automotive cruise control, aerospace guidance telemetry, phase array radar, etc.

PrePreg Material
It announced TerraGreen, a halogen-free, ultra-low loss, RF/microwave/high-speed material. TerraGreen is engineered for such high-performance applications as power amplifier boards for 4G LTE base stations.

Benefits:

• Taconic

  PTFE and fiberglass fabric are the base materials for almost everything Taconic produces. The benefits of PTFE coatings are proven:

  · Temperature and chemical resistance

  · High dielectric strength

  · Dimensional stability under heat and pressure

  · Low electrical losses

  · Low-friction/non-stick smooth surface

• RF-35TC High TC, DK 3.5 base material

• CER-10 High DK Material, easily fabricated

• TRF-41, TRF-43,TRF-45 Low cost RF laminate with FR4 DK values

• TSM family of materials provides a solution to the difficulty of manufacturing high layer count multilayer PCBs with PTFE cores. The low fiberglass content of the TSM family allows more predictable multilayer manufacturing vs. non-woven materials.




Typical Applications:

• Microwave & RF Laminates
  Applications: automotive, LED, mechanical, medical, military, multilayer, RF/microwave, thin core packaging & flexible interconnect

  Applications: aerospace, apparel, automotive, carpet/flooring, chemical processing, composites, food processing, lamination, packaging, paper, plastics, PVC welding, rubber processing, screen printing and textile

Production Description :

Competitive Advantage:
1) With UL,ROHS,ISO,IPC
2).Lead time:3-10 working days
3)Competitive price best quality
4).Rich 20 years experience in High Tg Multilayer PCB .


What Information customer need to provide for quotation ?
1. PCB Gerber files ,protel,powerpcb,Autocad,etc.
2. BOM list for PCB assembly.
3. Send us your sample PCB or PCBA.
4. OEM is acceptable.
