High Performance Rogers 3003 + FR4 4 layer pcb Gold Plating With Resin hole plugging

Key Specifications/Special Features:
PCB features:
Layer: 4
Material: Rogers 3003+FR4
Thickness: 1.2mm
Copper: 1oz
Mini hole: 0.2mm
Mini width/space: 0.2mm/0.2mm
Finish: Gold Plating

Key Specifications/Special Features:
Key Specifications

Number of layers: 4L
Base-material: Rogers3003+FR4, TG150
Thickness: 1.2mm+/-10%
Final-Cu: 35um
Impedance: No
Blind and buried via: Yes
Min. Drill hole: 0.25mm
Min. Line space: 0.127mm
Min. Line width: 0.127mm
Mech. treatment: Routing
Surface treatment: Gold Plating
Solder-mask: Green
Legend-Print: white
100% E-test: Yes

Main Export Markets:
Asia
Australasia
Central/South America
Eastern Europe
Mid East/Africa
North America
Western Europe

Reasonable price and professional services.
UL,SGS,ISO9001,ISO14001,RoHS and ISO TS16949

QUOTE REQUIREMENTS FOR PCB AND PCB ASSEMBLY:
- Gerber File and Bom List;
- Quantity;
- Technical requirements for quoting reference;
- Clear pictures of PCB or PCB Assembly sample if avaliable.
- Inspection method for PCB Assembly.

Delivery & logistics
Samples in 1-5 days, volume order in 18days average
24 hours fastest quick turn service
Free samples/sample cost refund policy
Strong packing for long transportation
Best value-added service including shipping, warehousing and more

Available substrates:
RO4350B RO4003C TLX-8 (TACONIC) F4B Woven Glass-Reinforced PTFE
4mil(0.1mm) 8mil (0.203mm) 20mil(0.5mm)
10mil(0.254mm) 12mil(0.3mm) 30mil(0.762mm)
13.3mil(0.338mm) 20mil(0.508mm) 40mil(1.0mm)
20mil (0.508mm) 32mil(0.813mm)
30mil(0.762mm) 60mil(1.524mm)
60mil(1.524mm)

Typical Applications:

• Space Saving Circuitry
• Patch Antennas
• Satellite Communications Systems
• Power Amplifiers
• Aircraft Collision Avoidance Systems
• Ground Radar Warning Systems
• Datalink on cable systems
• Remote meter readers
• Power backplanes
• LMDS and wireless broadband
• Base station infrastructure

Parameter:

Following are some types introduction for Rigid PCB and High Frequency PCB:
FR4 PCB(2layer,4 layer,multilayer)
Rogers(RO4003,RO4350,RO5880,RO3003,RO3010,RO3206,RO3035,RO6010)
F4B high frequency pcb board
Taconic(TLX-8,TLX-9,TLC-32,TLY-5,RF-60A,CER-10,RF-30,TLA-35)
Arlon high frequency pcb board
ISOLA high frequency pcb board

At the same time, we also provide corresponding PCBA services as our customer’s design and requirement.

Company Service:
24 hours quick sample is avaliable here.
reply Customer's any enquiry within 3 hours;
Blind buried hole ,crossed blind hole can be done
24 hours Engineering Gerber files treatment.
24 hours English Engineering Questions Confirmation by E-mail.
Supply the best project fit for production customized

Sincerely look forward to cooperating with you.
If you have a product quotation, please do not hesitate to contact us, thank you!

Karen-Sales Department
ShenZhen Xinchenger Electronics Co.,Ltd
sales3@xcepcb.com
Skype:karen-xcepcb

www.fr4-pcb.com/www.xce-pcb.com
